Switch Product
Series Number
RR
DSA
DL
Appearance
Features
Round Rocker Switch
LED, Neon or Tungsten Lamp
Illumination
Multiple Printing Styles
Multiple Color Options
Double Action Key Switch
Single Action Available
Small Compact Design
Large Actuator Surface
Horizontal Pushbutton Switch
Piggyback Style Available
Multiple Cap Styles
2 ~ 10 Poles
Interlocked/Ganged Option
Poles
SPST & SPDT
SPST NO & SPDT
DPDT ~ 10PDT
Function
Multiple
Momentary Double Action
Latching & Momentary
Contact Rating
up to 15A
up to 30mA
up to 500mA
Series Number
RPH
MP
LP
Appearance
Features
Horizontal Pushbutton Switch
PC Terminal or Snap-In PC
Panel Mount Chassis
2 ~ 6 Poles
Horizontal Pushbutton Switch
Solder Lug or PC Pin Terminal
Two Case Styles
PC or Panel Mount
Miniature Pushbutton Switch
Numerous Cap Styles
PC Terminal or Snap-In PC
2 ~ 4 Pole
Poles
DPDT, 4PDT & 6PDT
SPDT & DPDT
DPDT & 4PDT
Function
Latching & Momentary
Latching & Momentary
Latching & Momentary
Contact Rating
up to 100mA
up to 100mA
up to 100mA
Series Number
MS, 1000 & 1000A
DIP
SM3 & VM3
Appearance
Features
Miniature & Sub-Miniature
Standard & Right Angle
Multiple Actuator Lengths
Steel & Nylon Housings
Thru Hole, Surface Mount & Panel
DIP Switch
Full & Low Profile Styles
Standard, Half Pitch, Piano
& Right Angle
Thru Hole & Surface Mount
Mini & Sub-Mini Snap Action
3 Actuation Force Options
Multiple Lever Options
.Multiple Terminal Options
UL E222871
Poles
SPDT ~ 4P3T
SPST ~ 12PST
SPST N.C. & N.O.
Function
Multiple
On-Off
Momentary
Contact Rating
up to 5A
up to 25mA
up to 16A
