page 7
New Product
Contactors
HVAC
Electrical Motors
Lighting
Pump Controls
Contact Data
Applications Include
Contact Arrangement
DPST-NO-DM (double make per pole)
3PST-NO-DM (double make per pole)
Contact Data
30 full load amp
60 full load amp per pole 600V max
Contact Material
AgCdO
Coil Voltage
24VAC @ 50/60Hz
Coil Resistance
18 Ohms & 2.4 Ohms
Maximum Pick-Up Voltage
18VAC
Maximum Drop-Out Voltage
6 ~ 15VAC
Minimum In-Rush VA @ 50HZ 31 watts & 138 watts
Minimum In-Rush VA @ 60Hz 28 watts & 130 watts
Maximum Coil Voltage
30VAC
Dielectric Strength
2200VAC
Insulation Class
UL Class B (130 C)
Operating Temperature
-40 C to 65 C
Weight
273g & 635g typically
Contact CIT Sales for more information
Agricultural Equipment
Battery Chargers
Elevators
And Much More
