J104D
J107E1
J107F
High Sensitivity, Low Cost
Conforms to FCC Part 68
Clearance >1.2mm Between Coil and Contacts
Creepage >1.9mm Between Coil and Contacts
Bifurcated Contacts for High Reliability
Small Size, Light Weight
PC Board Mounting
UL / cUL Certified
Economy Version
F Class Insulation Standard
Small Size, Light Weight
PC Board Mounting
UL / cUL Certified
20.4 x 10.05 x 11.0
19.0 x 15.5 x 15.3
19.0 x 15.5 x 15.3
2C
1A, 1B, 1C
1A, 1B, 1C
AgNi + Au Clad
AgSnO 2
AgSnO 2
2A @ 24VDC Resistive
1A @ 120VAC Resistive
10A @ 250VAC
10A @ 30VDC
20A Contact
20A @ 16VDC / 125VAC General Purpose
10A @ 250VAC General Purpose
1/3hp @ 125VAC / 277VAC
15A Contact
15A @ 125VAC General Purpose
6A @ 227VAC General Purpose
12A Contact
12A @ 125VAC / 28VDC General Purpose
3 ~ 48VDC
3 ~ 24VDC
5 ~ 24VDC
.15W, .20W, .36W & .45W
.36W & .45W
.36W, .45W & .80W
< 50m
< 50m
< 50m
100M
@ 500VDC
100M
@ 500VDC
100M
@ 500VDC
100K cycles
100K cycles
100K cycles
10M cycles
10M cycles
10M cycles
500V rms
1000V rms
750V rms
1500V rms
750V rms
1500V rms
-40
°
C to 85
°
C
-40
°
C to 85
°
C
-55
°
C to 125
°
C
PC Pin
PC Pin
PC Pin
7.62
[.30]
7.62
[.30]
5.08
[.20]
5.08
[.20]
(8X)
Ø1.00
[.04]
E197851
E197851
E197851
