J115F3
J115F_E
J117F
F Class Insulation Standard
Small Size, Light Weight
Heavy Contact Load
Strong Shock & Vibration Resistance
UL / cUL & TÜV Certified
30A Economical Version
Small Size, Light Weight
Low Coil Power Consumption
Strong Shock & Vibration Resistance
UL / cUL & TÜV Certified
F Class Insulation Standard
Low Profile : 12.3mm
Narrow Width
High Dielectric Strength
Creepage > 8mm Between Coil and Contacts
32.4 (50.0) x 26.8 x 28.1
21.5 x 15.8 x 16.5
28.5 x 10.1 x 12.3
1A, 1B, 1C
1A, 1B, 1C
1A, 1C
AgSnO 2, AgSnO 2 In 2 O 3
AgSnO 2, AgCdO
AgSnO 2
NO : 40A @ 240VAC Resistive; 20A @ 240VAC Resistive, 250k cycles
30A @ 277VAC General Purpose; 25A @ 277VAC Resistive,
100k cycles; 5A @ 280VAC Ballast; 2hp @ 250VAC
TÜV NO : 30A @ 240VAC; 14VDC
NC : 20A @ 240VAC; 14VDC
8A @ 250VAC
8A @ 30VDC
100K Cycles @ 70
°
C Ambient
NC : 30A @ 240VAC Resistive; 20A @ 240VAC General Purpose;
20A @ 277VAC General Purpose; 30A @ 30VDC Resistive;
5A @ 280VAC Ballast; 1 1/2hp @ 250VAC
UL Rating NO : 30A @ 240VAC Resistive
NC : 20A @ 240VAC Resistive
5 ~ 110VDC & 12 ~ 277VAC
5 ~ 110VDC
9 ~ 24VDC
DC : .60W & .90W AC : 2VA
.60W & .90W
.22W
< 30m
< 30m
< 50m
1000M
@ 500VDC
100M
@ 500VDC
100M
@ 500VDC
100K cycles
100K cycles
100K cycles
10M cycles
10M cycles
10M cycles
1500V rms
2500V rms
1500V rms
2500V rms & 4000V rms
1000V rms
5000V rms
-55
°
C to 125
°
C
-55
°
C to 125
°
C
-55
°
C to 125
°
C
Panel Mount
PC Pin, Panel Mount
PC Pin
UL E197852 / TÜV
UL E197852 / TÜV
E197851
