UL Recognized
J151
J152
J850 / J850SM
Switching Capacity up to 20A
Low Coil Power Consumption
High Contact Load
Strong Resistance to Shock & Vibration
Switching Capacity up to 10A
Low Coil Power Consumption
High Contact Load
Strong Resistance to Shock & Vibration
Monostable
Conforms to FCC Part 68
Ultra Low Profile : 4.90mm Height
UL / cUL Certified
21.6, 30.6, 40.6 x 27.6 x 35.0
27.0 x 21.0 x 35.0
14.0 x 9.0 x 4.9
1A, 2A, 3A, 4A, 1B, 2B, 3B, 4B, 1C, 2C, 3C, 4C
2A, 3A, 4A, 2B, 3B, 4B, 2C, 3C, 4C
2C
AgCdO
AgCdO
AgPd Stationary Contact, Au Plated
1 Pole
20A @ 277VAC General
20A @ 28VDC General
2, 3 & 4 Pole
12A @ 250VAC General
12A @ 28VDC General
10A @ 277VAC General
1/2hp @ 125VAC
2 & 3 Pole
10A @ 220VAC General
10A @ 28VDC General
4 Pole
5A @ 220VAC General
5A @ 28VDC General
1A @ 30VDC Resistive
.5A @ 125VAC Resistive
12 ~ 220VDC & 12 ~ 240VAC
12 ~ 110VDC & 12 ~ 220VAC
3 ~ 24VDC
DC : .9W, 1.4W & 1.5W & AC : 1.2W, 2W & 2.5W
DC : .90W & AC : 1.2W
.14W & .20W
< 50m
< 50m
< 50m
100M
@ 500VDC
100M
@ 500VDC
100M
@ 500VDC
100K cycles
100K, 200K or 500K cycles
200K cycles
10M or 20M cycles
10M or 20M cycles
100M cycles
1500V rms
1500V rms
1500V rms
1500V rms
1000V rms
1000V rms
-40
°
C to 85
°
C
-40
°
C to 85
°
C
-40
°
C to 85
°
C
PC Pin, Solder Lug
PC Pin, Solder Lug
PC Pin
E197852
E197851
E197851
