25 / 36
www.citrelay.com
phone - 763.535.2339 fax - 763.535.2194
Dimensions shown in mm. Dimensions are shown for reference purposes only.
Speci cations and availability subject to change without notice.
Automotive
page 25
A16
A17
Small Size, Light Weight
25A Switching Capacity
F Class Insulation Standard
QS-9000, ISA-9002 Certified Manufacturing
Switching Capacity up to 20A
Small Size and Light Weight
Suitable for Automotive & Lamp Accessories
14.5 x 7.7 x 13.7
16.5 x 15.5 x 24.3
1C
1A
AgSnO 2 In 2 O 3
AgSnO 2
25A @ 14VDC
20A @ 14VDC NO
12VDC
12VDC
.64W & .80W
.96W
< 50m
< 50m
100M
@ 500VDC
100M
@ 500VDC
100K cycles
100K cycles
10M cycles
10M cycles
1000V rms
1500V rms
500V rms
750V rms
-40
°
C to 105
°
C
-40
°
C to 85
°
C
PC Pin
PC Pin
7.80
[.31]
8.00
[.31]
(4X) Ø3.00
[.12]
87
86
30
85
