21 / 36
Dimensions shown in mm. Dimensions are shown for reference purposes only.
Speci cations and availability subject to change without notice.
Automotive
page 21
www.citrelay.com
phone - 763.535.2339 fax - 763.535.2194
A1
A1M
A2
Switching Capacity up to 25A
Suitable for Automobile & Lamp Accessories
PCB Pin & Quick Connect Mounting
Switching Capacity up to 20A
PCB Pin & Quick Connect Mounting
Suitable for Automobile & Lamp Accessories
Large Switching Capacity up to 40A
PCB Pin & Quick Connect Mounting
Suitable for Automotive & Lamp Accessories
Two Style Mounting Flange Available
22.8 x 15.3 x 25.8
20.0 x 15.2 x 22.0
26.0 x 26.0 x 24.5 (39.5)
1A, 1C
1A, 1B
1A, 1B, 1C, 1U
AgSnO 2
AgSnO 2
AgSnO 2
1A : 25A @ 14VDC
1C : 20A @ 14VDC
1A : 20A @ 14VDC
1B : 15A @ 14VDC
1A : 40A @ 14VDC
1B : 30A @ 14VDC
1C : 40A @ 14VDC NO
1C : 30A @ 14VDC NC
1U : 2x20A @ 14VDC
6 ~ 48VDC
12VDC & 24VDC
6VDC, 12VDC, 24VDC & 48VDC
1.2W & 1.5W
1.16W
1.6W & 1.9W
< 50m
< 50m
< 30m
100M
@ 500VDC
100M
@ 500VDC
100M
@ 500VDC
100K cycles
100K cycles
100K cycles
10M cycles
10M cycles
10M cycles
1500V rms
2500V rms
1000V rms
1500V rms
500V rms
750V rms
-40
°
C to 85
°
C
-40
°
C to 85
°
C
-40
°
C to 125
°
C
PC Pin, Quick Connect
Quick Connect
PC Pin, Quick Connect
1C
