Sockets
RoHS Compliant
Used with J114FL/J114AF, J151, J152, A2 & A9 relays
Snap-In, PC Pin and Screw Terminal Types
Secure t for relay
Easy installation of relay onto PC Board
Hold down clips also available
Ordering Information
UL Recognized sockets are shaded
Features
A2 / A9
J114FL /
J114AF /
L114FL
J151 2C J151 3C J151 4C J152 2C J152 3C J152 4C
Panel Mount /
Wire Assembly
HD-1001
HD-1002
PT08
PY08
PY11
PY14
PC Pin
HD-1003 P2R05P
P2R08P PT08-0 PT11A
PY08-02 PY11-02 PY14-02
DIN Rail
Mountable
P2F08S PTF08A PTF11A PTF14A PYF08A PYF11A PYF14A
DIN Rail
Mountable
Finger Safe
P2F08N PTF08A-E
PYF08A-E PYF11A-E PYF14A-E
