Automotive
A5
A6
A9
Switching Capacity up to 40A
Small Size, Light Weight
Suitable for Automotive & Lamp Accessories
Two Footprint Styles Available
Low Coil Power Consumption
Small Size, Light Weight
Switching Current up to 30A
Suitable for Household Appliances and
Automotive Applications
Switching Capacity up to 40A
Accomodates Standard Sized Automotive
Fuse
Insert Mounting Footprint
Metal Mounting Tab
25.8 x 20.5 x 20.8
22.5 x 15.0 x 25.2
35.5 x 25.5 x 21.0
1A, 1B, 1C
1A, 1C
1A
AgSnO 2
AgSnO 2
AgSnO 2
1A : 40A @ 14VDC
20A @ 120VAC
15A @ 28VDC
1B : 30A @ 14VDC
20A @ 120VAC
15A @ 28VDC
1C : 40A @ 14VDC
30A @ 14VDC
20A @ 120VAC
15A @ 28VDC
1A : 30A @ 14VDC
1C : 30A @ 14VDC NO
1C : 20A @ 14VDC NC
40A @ 14VDC
6 ~ 24VDC
12 ~ 24VDC
6 ~ 24VDC
1.6W & 1.9W
.9W & 1.3W
1.8W
< 50m
< 50m
< 50m
100M
@ 500VDC
100M
@ 500VDC
100M
@ 500VDC
100K cycles
100K cycles
100K cycles
10M cycles
10M cycles
10M cycles
750V rms
500V rms
500V rms
500V rms
500V rms
750V rms
-40
°
C to 85
°
C
-40
°
C to 85
°
C
-40
°
C to 105
°
C
Quick Connect
PC Pin
Socket
