J112
J114AF
J114FL
Low Power Consumption - .12W
Ultra Light Weight
Narrow Width Ideal for High Density
Mounting
UL / cUL Certified
Switching Capacity up to 16A
20mm Height
PC Board Mounting
UL / cUL & TÜV Certified
F Class Insulation Standard
Switching Capacity up to 16A
Low Profile : 15.7mm
F Class Insulation Standard
UL / cUL Certified
20.2 x 5.3 x 12.8
29.0 x 12.7 x 20.0
29.0 x 12.6 x 15.7
1A
1A, 1C, 2A, 2C
1A, 1C, 2A, 2C
AgNi + Au Clad
AgSnO 2
AgSnO 2
5A @ 250VAC Resistive, 70
°
C, 20k cycles
5A @ 30VDC Resistive, 70
°
C, 20k cycles
1A & 1C : 16A @ 250VAC, 30VDC, Resistive, 70
°
C
1AH & 1CH : 16A @ 240VAC, 30VDC, Resistive
2A & 2C : 8A @ 250VAC, Resistive, 70
°
C
2A & 2C : 5A @ 30VDC, Resistive, 70
°
C
12A @ 250VAC, 30VDC General Purpose,
85
°
C
16A @ 250VAC, 30VDC General Purpose,
85
°
C
8A @ 250VAC, 30VDC General Purpose,
85
°
C
1AH : 16A @ 240VAC, 130VDC, 100K cycles
16(3)A @ 240VAC, 100K cycles
1CH : 16A @ 240VAC, 130VDC, 100K cycles
16(4)A @ 240VAC, 30K cycles
5 ~ 24VDC
3 ~ 48VDC
5VDC ~ 48VDC
.12W & .18W
.53W & .72W
.41W
< 50m
< 50m
< 50m
100M
@ 500VDC
100M
@ 500VDC
1000M
@ 500VDC
100K cycles
100K cycles
100K cycles
10M cycles
10M cycles
10M cycles
1000V rms
2000V rms
1000V rms
5000V rms
1000V rms
5000V rms
-40
°
C to 85
°
C
-55
°
C to 105
°
C
-55
°
C to 105
°
C
PC Pin
PC Pin
PC Pin
E197851
UL E197851 / TÜV
E197851
page 15
www.citrelay.com
phone - 763.535.2339 fax - 763.535.2194
TÜV Spec
UL Spec
