New Product
Latching Relays
CIT Relay & Switch is your source for new technology.
Call today!
1
2
4 7 3
9 6 8
S R
+
+
-
-
20.00
[.79]
5.00
[.20]
5.00
[.20]
7.60
[.30]
8X Ø1.30
[.05]
L114FL Series - 16 Amp
Schematic & PCB Layout
7.70
[.30]
17.80
[.70]
(3X) Ø 2.10
[.08]
3.80
[.15]
10.20
[.40]
(2X) Ø 1.10
[.04]
15.40
[.61]
2.54
[.10]
+ -
- +
S R
L115F1 Series - 50 Amp
Schematic & PCB Layout
CIT Relay & Switch now offers two latching relays - the L115F1 Series with switching
capacity up to 50 amps and the L114 Series, with switching capacity up to 16 amps. Both
series are UL/cUL approved and can withstand heavy contact load with strong shock and
vibration resistance. The L115F1 Series is a single coil relay and the L114 is available in
both single coil and double coil. The CIT Relay & Switch latching relays are UL F class
rated standard and are ideal for energy smart applications.
