Right Angle Switches
CIT Relay & Switch offers a number of electronic switches with right angle termination. We offer slide switches in both miniature and sub-miniature sizes, pushbutton switches in many difference sizes, in rocker, toggle, and tactile switch options. Many of our right angle switches are available in sealed and surface mount versions.
Series | Models | Type | Features | Electrical Ratings | Options |
---|---|---|---|---|---|
1000 Series | Slide | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Miniature Size, Standard and Right Angle, Multiple Actuator Lengths, Steel and Nylon Housings |
5A@120VAC, 5A@28VDC, 2A@250VAC | ||
1000A Series | Slide | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Sub-Miniature Size, Standard and Right Angle, Steel and Nylon Housings |
3A@120VAC, 3A@28VDC, 1A@250VAC | ||
ANP Series | Pushbutton | Latching Options: Momentary, Latching Mounting Style: Panel Mount, Through-Hole Miniature Size, Wide Variety of Terminals, Panel Mount, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1A@250VAC | Illuminated | |
ANR Series | Rocker | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Miniature Size, Up to 4 Poles with 6 Functions, Wide Variety of Actuator Styles, Gold Contacts Available |
5A@120VAC, 5A@28VDC, 2A@250VAC | Illuminated | |
ANT Series | Toggle | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Miniature Size, Flat Toggles with Anti-Rotation Option, Wide Variety of Actuator Styles, Gold Contacts Available |
5A@120VAC, 5A@28VDC, 2A@250VAC | ||
ASP Series | Pushbutton | Latching Options: Momentary Mounting Style: Panel Mount, Through-Hole Miniature Size, IP67 Process Sealed, Wide Variety of Terminals, Panel Mount, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1A@250VAC | Sealed | |
ASR Series | Rocker | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Miniature Size, IP67 Process Sealed, Up to 4 Poles with 6 Functions, Wide Variety of Actuator Styles, Gold Contacts Available |
5A@120VAC, 5A@28VDC, 2A@250VAC | Sealed | |
AST Series | Toggle | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Miniature Size, IP67 Process Sealed, Flat Toggles with Anti-Rotation Option, Wide Variety of Actuator Styles, Gold Contacts Available |
5A@120VAC, 5A@28VDC, 2A@250VAC | Sealed | |
BNP Series | Pushbutton | Latching Options: Momentary Mounting Style: Panel Mount, Through-Hole Sub-Miniature Size, Wide Variety of Terminals, Panel Mount, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1A@250VAC | ||
BNR Series | Rocker | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Sub-Miniature Size, Up to 4 Poles with 6 Functions, Wide Variety of Actuator Styles, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1A@250VAC | ||
BNT Series | Toggle | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Sub-Miniature Size, Flat Toggles with Anti-Rotation Option, Wide Variety of Actuator Styles, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1A@250VAC | ||
BSP Series | Pushbutton | Latching Options: Momentary Mounting Style: Through-Hole Sub-Miniature Size, IP67 Process Sealed, Wide Variety of Terminals, Panel Mount, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1A@250VAC | Sealed | |
BSR Series | Rocker | Latching Options: Multiple Mounting Style: Through-Hole Sub-Miniature Size, IP67 Process Sealed, Up to 4 Poles with 6 Functions, Wide Variety of Actuator Styles, Gold Contacts Available |
3A@120VAC, 3A@28VDC, 1.5A@250VAC | Sealed | |
CL1200 Series | Tactile | Latching Options: Momentary Mounting Style: Through-Hole, Surface Mount Bi-Color LED Option, Multiple Cap Styles, Surface Mount & Right Angle Options |
50mA@48VDC | Illuminated | |
CS1102V Series | Tactile | Latching Options: Momentary Mounting Style: Surface Mount Surface Mount, Multiple Actuator Length Options, Multiple Actuator Force Options |
50mA@50VDC | ||
CSP Series | Pushbutton | Latching Options: Momentary Mounting Style: Through-Hole Sub-Miniature Size, IP67 Process Sealed, Single or Double Pole Option |
.4VA@20VAC or VDC | Sealed | |
CSR Series | Rocker | Latching Options: Multiple Mounting Style: Through-Hole Sub-Miniature Size, Process Sealed, Single or Double Pole Option |
.4VA@20VAC or VDC max | Sealed | |
CST Series | Toggle | Latching Options: Multiple Mounting Style: Through-Hole Sub-Miniature Size, IP67 Process Sealed, Single or Double Pole Option, Gold Plated Contacts, PC Pin, Vertical or Horizontal Mount |
.4VA@20VAC or VDC max | Sealed | |
CT1102V Series | Tactile | Latching Options: Momentary Mounting Style: Through-Hole Right Angle, Through-Hole, Actuator Length Options, Actuation Force Options, Multiple Cap Options |
50mA@50VDC | ||
CW Series | Tactile | Latching Options: Momentary Mounting Style: Through-Hole, Surface Mount Available both Surface Mount and Through-Hole, Dual Color LED Option, Silver or Gold Contact Material |
50mA@48VDC | Illuminated | |
DL Series | Horizontal Pushbutton | Latching Options: Momentary, Latching Mounting Style: Panel Mount, Through-Hole Horizontal Style, Piggyback Style Available, Multiple Cap Choices, Interlocked/Ganged Option |
Contact Factory | ||
DS Series | Horizontal Pushbutton | Latching Options: Momentary Mounting Style: Through-Hole Horizontal Style, Bi-Color LED Option, PC Mount, Available with or without Cap |
200mA@30VDC | Illuminated | |
LPH Series | Horizontal Pushbutton | Latching Options: Momentary, Latching Mounting Style: Through-Hole Bi-Color LED Option, Multiple Finish Options, Laser Etching Option, Right Angle |
300mA@30VDC | Illuminated | |
MH Series | Pushbutton | Latching Options: Momentary Mounting Style: Through-Hole Right Angle, Bi-Color LED Option, Over-Travel and Positive Feel, Available with or without Cap |
100mA@30VDC | Illuminated | |
MS1206 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Sub-Miniature Size, Multiple Actuator Lengths, Steel Housing |
200mA@30VDC | ||
MS1247 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Sub-Miniature Size, Multiple Actuator Lengths, Steel Housing |
200mA@30VDC | ||
MS1271 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Sub-Miniature Size, Right Angle Option, Actuator Color Options, Steel & Nylon Housing |
200mA@30VDC | ||
MS2208 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Miniature Size, Multiple Actuator Lengths, Steel Housing |
500mA@15VDC | ||
MS2210 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Miniature Size, Multiple Actuator Lengths, Steel Housing |
200mA@30VDC | ||
MS2211 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Sub-Miniature Size, Steel Housing |
200mA@30VDC | ||
MS2219 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Miniature Size, Steel Housing |
200mA@30VDC | ||
MS2241 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Miniature Size, Multiple Actuator Lengths, Steel Housing |
100mA@30VDC | ||
MS2309 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Miniature Size, Multiple Actuator Lengths, Multiple Positions, Steel Housing |
300mA@50VDC | ||
MS2310 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Sub-Miniature Size, Multiple Actuator Lengths, Multiple Positions, Steel Housing |
300mA@50VDC | ||
MS4208 Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Right Angle, Miniature Size, Multiple Actuator Lengths, Steel Housing |
200mA@30VDC | ||
RA Series | Rocker | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Illuminated Option, Multi-Function, Multiple Actuator Marking Options, Right Angle Option, IP40 or IP65 |
UL61058-1, 15A@125VAC, 10A@250VAC | Illuminated | |
RC Series | Rocker | Latching Options: Multiple Mounting Style: Panel Mount, Through-Hole Illuminated Option, Multi-Function, Multiple Actuator Marking Options, Right or Left Angle Option, IP40 |
UL61058-1, 12A@125VAC, 12A@250VAC, TV5@125VAC | Illuminated | |
RPH Series | Horizontal Pushbutton | Latching Options: Momentary, Latching Mounting Style: Panel Mount, Through-Hole Miniature Horizontial Style, PC Terminal or Snap-In PC Terminal Options, Panel Mount Chassis Option |
100mA@30VDC | ||
SMS Series | Slide | Latching Options: Multiple Mounting Style: Through-Hole Process Sealed, Sub-Miniature |
0.4mA@20VAC or VDC max | Sealed | |
SSP Series | Horizontal Pushbutton | Latching Options: Momentary Mounting Style: Surface Mount IP67 Process Sealed, Surface Mount, Silver or Gold Plated Contacts |
1A@250VAC, 3A@120VAC | Sealed | |
SST Series | Toggle | Latching Options: Multiple Mounting Style: Surface Mount IP67 Process Sealed, Surface Mount, Silver or Gold Plated Contacts |
3A@120VAC, 1.5A@250VAC | Sealed | |
STJV Series | Tactile | Latching Options: Momentary Mounting Style: Through-Hole IP67 Process Sealed, Right Angle, Gold or Silver Contact Option, Multiple Actuation Force Options |
50mA@48VDC | ||
STV Series | Tactile | Latching Options: Momentary Mounting Style: Through-Hole Right Angle, Surface Mount, Stainless Steel Dome Option, Multiple Actuation Force Options |
50mA@48VDC |
